Roll Forming Machine
Basic Info
Model No.: roll forming machine
Product Description
Model NO.: Roll Forming Machine Voltage: 380V Customized Forming Method: Cold Roll Forming Trademark: HKYRFM Origin: China Series: Roof Rolling Machine Thickness Range: 0.2-1.2mm Electronic: PLC Specification: 7.5*1.6*1.4M HS Code: 8474801000 About us
BOTOU HUIKEYUAN ENGINEERING CONTROL CO, . LTD
is the "Important individually-run enterprise"of Botou City. For 20 years we have devoted ourselves to manufacture of metal-plate cold forming machines and now we have achieved unique management pattern and product development ability Our advantage
[] Excellent reputation for sound and innovatitive engineering
The use of CAD CAM technology ensures the highest standard of forming precision
[] Experienced technicians team
Good at installing and debugging and ensure the machine run durably and smoothly
[] Experience in exporting to oversea countries
Engineers available to service machinery overseas
[] 2 years warranty - double than general
The warranty is effective for the whole production line with free replacements.
Technical Parameters
1. Main Motor Power: 5.5KW
2. Hydraulic Station Power: 4KW
3. Hydraulic Oil Pump: CB-E210
4. Sprocket: P-25.4
5. Roller Station: 14
6. Yield Strength: 12-32MPa
7. Diameter of main shaft: 95mm
8. Material of Roller: 45#steel hard chrome plating
9. Material of Blade: Cr12mov
10. Processing Speed: 8-12 mtrs/min
11. Thickness: 0.2-2mm
12. Installation Dimension (L*W*H): 7.5m*1.5m*1.4m
13. Total Weight: 5.5T
TERMS
1. Delivery: 30 days
2. Package: Seaworthy Packing
3. Payment: L/C, T/T
4. Validity: Please send an online enquiry for latest price
REMARKS
1. The machine is designed acc. to your requirement
2. Within 2-year warranty if it goes broken new part will be sent freely as replacement
SERVICE
2 years warranty. after warranty, we repair the machine and customer pay for the labour and parts when the machine have a problem
EXPORT MARKET
Russia, the UK, India, Australia, the US, Kazakhstan, Tajikistan, Malaysia, Nigeria,
Rumania and Albania etc..
Contact us if you need more details on Roll Forming Machine. We are ready to answer your questions on packaging, logistics, certification or any Other aspects about Roll Forming Machinery、Rolling Machine. If these products fail to match your need, please contact us and we would like to provide relevant information.
BOTOU HUIKEYUAN ENGINEERING CONTROL CO, . LTD
is the "Important individually-run enterprise"of Botou City. For 20 years we have devoted ourselves to manufacture of metal-plate cold forming machines and now we have achieved unique management pattern and product development ability Our advantage
[] Excellent reputation for sound and innovatitive engineering
The use of CAD CAM technology ensures the highest standard of forming precision
[] Experienced technicians team
Good at installing and debugging and ensure the machine run durably and smoothly
[] Experience in exporting to oversea countries
Engineers available to service machinery overseas
[] 2 years warranty - double than general
The warranty is effective for the whole production line with free replacements.
Technical Parameters
1. Main Motor Power: 5.5KW
2. Hydraulic Station Power: 4KW
3. Hydraulic Oil Pump: CB-E210
4. Sprocket: P-25.4
5. Roller Station: 14
6. Yield Strength: 12-32MPa
7. Diameter of main shaft: 95mm
8. Material of Roller: 45#steel hard chrome plating
9. Material of Blade: Cr12mov
10. Processing Speed: 8-12 mtrs/min
11. Thickness: 0.2-2mm
12. Installation Dimension (L*W*H): 7.5m*1.5m*1.4m
13. Total Weight: 5.5T
TERMS
1. Delivery: 30 days
2. Package: Seaworthy Packing
3. Payment: L/C, T/T
4. Validity: Please send an online enquiry for latest price
REMARKS
1. The machine is designed acc. to your requirement
2. Within 2-year warranty if it goes broken new part will be sent freely as replacement
SERVICE
2 years warranty. after warranty, we repair the machine and customer pay for the labour and parts when the machine have a problem
EXPORT MARKET
Russia, the UK, India, Australia, the US, Kazakhstan, Tajikistan, Malaysia, Nigeria,
Rumania and Albania etc..
