Home > Products > Roof & wall roll forming machine > Machine Roofing China Milling machine

Machine Roofing China Milling machine

Productivity:
25 Sets/Year
Place of Origin:
China
Supply Ability:
25 Sets/Year

Basic Info

Model No.:  machine

Product Description

Model NO.: machine Voltage: 380V Customized Forming Method: Cold Roll Forming Trademark: HKYRFM Origin: China Series: Roof Rolling Machine Thickness Range: 0.2-1.2mm Electronic: PLC Specification: 7.5*1.6*1.4M HS Code: 8474801000 About us
BOTOU HUIKEYUAN ENGINEERING CONTROL CO, . LTD
  is the "Important individually-run enterprise"of Botou City. For 20 years we have devoted ourselves to manufacture of metal-plate cold forming machines and now we have achieved unique management pattern and product development abilityMachine Roofing China Milling machine  Our advantage
   [] Excellent reputation for sound and innovatitive engineering
        The use of CAD CAM technology ensures the highest standard of forming precision
   [] Experienced technicians team
       Good at installing and debugging and ensure the machine run durably and smoothly
   [] Experience in exporting to oversea countries
       Engineers available to service machinery overseas
   [] 2 years warranty - double than general
       The warranty is effective for the whole production line with free replacements.
Machine Roofing China Milling machine
Technical Parameters

      1. Main Motor Power: 5.5KW
      2. Hydraulic Station Power: 4KW
      3. Hydraulic Oil Pump: CB-E210

      4. Sprocket: P-25.4
      5. Roller Station: 14
      6. Yield Strength: 12-32MPa

      7. Diameter of main shaft: 95mm
      8. Material of Roller: 45#steel hard chrome plating
      9. Material of Blade: Cr12mov

      10. Processing Speed: 8-12 mtrs/min
      11. Thickness: 0.2-2mm
      12. Installation Dimension (L*W*H): 7.5m*1.5m*1.4m
      13. Total Weight: 5.5T

Machine Roofing China Milling machine

TERMS
1. Delivery: 30 days
2. Package: Seaworthy Packing
3. Payment: L/C, T/T
4. Validity: Please send an online enquiry for latest price


REMARKS
1. The machine is designed acc. to your requirement
2. Within 2-year warranty if it goes broken new part will be sent freely as replacement



SERVICE
2 years warranty. after warranty, we repair the machine and customer pay for the labour and parts when the machine have a problem


EXPORT MARKET
Russia, the UK, India, Australia, the US, Kazakhstan, Tajikistan, Malaysia, Nigeria,
Rumania and Albania etc..
